| Types | Volume of Fuel (Kg/h) | Methods of Control | Power | Fan Motor (Kw) | Heater (Kw) | Air Compressor (Kw) |
| HM-50 | 15-50 | H/L/OFF | 3 | 0.75 | 5 | 0.75 |
| HM-100 | 30-90 | " | 3 | 1.5 | 5 | 0.75 |
| HM-150 | 40-140 | " | 3 | 2.2 | 5 | 1.5 |
| HM-200 | 50-180 | " | 3 | 3.7 | 7 | 1.5 |
| HM-250 | 60-240 | " | 3 | 5.5 | 8 | 2.2 |
| Types | A | B | C | L | H | I | J | W |
| 50 | 165 | 130 | 630 | 760 | 580 | 282 | 328 | 610 |
| 75 | 165 | 130 | 630 | 760 | 580 | 292 | 358 | 650 |
| 100 | 180 | 160 | 730 | 890 | 570 | 337 | 363 | 700 |
| 150 | 200 | 200 | 810 | 1010 | 590 | 380 | 380 | 760 |
| 200 | 240 | 225 | 825 | 1050 | 620 | 355 | 445 | 800 |
| 250 | 240 | 225 | 825 | 1050 | 620 | 355 | 485 | 840 |
| Types | d1 | d2 | d3 | d4 | d5 | bore gauge | Flame(L m/m) | Flame(L m/m) | Volume(Kg/h) |
| 50 | 165 | M10 | 196 | 170 | 115 | A | 1000-1300 | 380 | 50 |
| 75 | 165 | M10 | 196 | 170 | 115 | 1100-1400 | 400 | 75 | |
| 100 | 180 | M12 | 280 | 190 | 145 | 1200-1600 | 430 | 90 | |
| 150 | 200 | M12 | 280 | 210 | 170 | 1500-1900 | 450 | 140 | |
| 200 | 240 | M12 | 320 | 250 | 200 | 2000-2300 | 480 | 180 | |
| 250 | 240 | M12 | 320 | 250 | 200 | 2300-2500 | 500 | 240 |
